LUP YV Surface Mounted
Designed in two configurations, round and square, LUP adds an elegant atmosphere to your spaces by addressing a wide range of uses from hotels to offices, hospitals to residences. It provides the right light distribution by combining multiple power, light color, angle and control combinations with alternatives suitable for different areas. Its lenses can be easily replaced where it is mounted according to the required light angle.
-
Product Description
-
Technicial Specifications
-
Download Center
Designed in two configurations, round and square, LUP adds an elegant atmosphere to your spaces by addressing a wide range of uses from hotels to offices, hospitals to residences. It provides the right light distribution by combining multiple power, light color, angle and control combinations with alternatives suitable for different areas.
| Housing | Aluminium Housing |
| Optical | Lens |
| Optic Angles | 24° / 36° / 60° |
| IP Protection Class | IP20 |
| Input Voltage | 220-240V AC 50/60 Hz |
| Consumption Power | 8W / 10W / 14W |
| Light of Source | COB LED |
| Color Temperature | 2700K / 3000K / 4000K / 6500K |
| CRI | >80 / >90 |
| Working Ambient Temperature | -5 °C / +35 °C |
| Body Colors | RAL 9005 / RAL 9016 / RAL 7016 |
| Installation | Surface Mounted |
