PICA TRACK
PICA TRACK SPOT uses a simple and polite language with its layered body structure that covers the cooling fins. Vertically positioned driver box displays a compact appearance. It meets all the requirements of accent lighting technique with different optical and lumen values.
-
Product Description
-
Technicial Specifications
-
Download Center
-
Datasheets
PICA TRACK SPOT uses a simple and polite language with its layered body structure that covers the cooling fins. Vertically positioned driver box displays a compact appearance. It meets all the requirements of accent lighting technique with different optical and lumen values.
| Housing | Aluminium Injection Housing |
| Optical | Reflector |
| Optical Angles | 15° / 30° / 45° |
| IP Protection Class | IP20 |
| IK Impact Resistance Class | IK03 |
| Input Voltage | 220-240V AC 50/60 Hz |
| Consumption Power | 20 W / 30 W |
| Source of Light | COB LED |
| Color Temperature | 3000K / 4000K / 6500K |
| CRI | >80 / >90 |
| Working Ambient Temperature | -5 °C / +35 °C |
| Body Colors | RAL 9005 / RAL 9006 / RAL 9016 |
| Mounting Type | Three Phase Railed |
