BRICK 1X Surface Mounted
BRICK is available in different sizes and alternatives. With its compact body design and deeply positioned light source that does not cause glare, it perfectly meets the regional and general lighting needs of all kinds of interiors. BRICK provides solutions to modern lighting concepts with its stylish surface-mounted design.
-
Product Description
-
Technicial Specifications
-
Download Center
BRICK is available in different sizes and alternatives. With its compact body design and deeply positioned light source that does not cause glare, it perfectly meets the regional and general lighting needs of all kinds of interiors.
| Housing | Aluminium Housing |
| Optical System | Reflector |
| Optical Angles | 24° / 36° |
| Optical Cover | Transparent Diffuser |
| IP Protection Class | IP20 |
| IK Impact Resistance Class | IK03 |
| Input Voltage | 220-240V AC 50/60 Hz |
| Consumption Power | 6 W / 8 W / 10 W /12 W |
| Lumen Value | 692 lm / 866 lm / 1099 lm / 1195 lm |
| Source of light | COB LED |
| Color Temperature | 2700K / 3000K / 4000K / 6500K |
| CRI | >80 |
| Working Ambient Temperature | -5 °C / +35 °C |
| Body Colors | RAL 9005 / RAL 9006 / RAL 9016 |
| Mounting Type | Surface Mounted |
