SNAIL MAXI
Designed according to the latest trends, S-NAIL is ideal for lighting objects, walls, paintings etc. with its aesthetic body designs and spot mechanism. It stands out with its optical diversity and different lumen values. It can be used effectively in sloping ceiling applications thanks to its steerability.
-
Product Description
-
Technicial Specifications
-
Download Center
-
Datasheets
Designed according to the latest trends, SNAIL is ideal for lighting objects, walls, paintings etc. with its aesthetic body designs and spot mechanism. It stands out with its optical diversity and different lumen values.
| Housing | Aluminium Housing |
| Optical | Reflector / Transparent Glass |
| Optical Angles | 15° / 30° / 45° / 60° |
| IP | IP20 |
| IK Impact Resistance Class | IK03 |
| Input Voltage | 220-240V AC 50/60 Hz |
| Power | 20 W / 30 W |
| Light Source | COB LED |
| Color Temperature | 2700K / 3000K / 4000K / 6500K |
| CRI | >80 / >90 |
| Working Ambient Tempera | -5 °C / +35 °C |
| Body Colors | RAL 9005 / RAL 9006 / RAL 9016 |
| Mounting Type | Recessed / Plasterboard |
